Features
1. The rear long-distance speed control device installed in the slurry seal equipment makes the construction go smooth and easy.
2. The emulsified asphalt tank and water tank are made of the corrosion-resistant composite materials to prolong their service life.
3. It is powered by the hydraulic drive system. The various systems are controlled independently so that there is no energetic disturbance to make sure the stable operation of this system.
4. The double shaft powerful agitator tank does not allow any dead corners and would clean the dead corners to make sure the mixture evenly distributed.
Category | Item | Unit | Parameter | |
Emulsified Asphalt System | Emulsified Asphalt Tank | l | 2800 | |
Max. Asphalt Flow | l/min | 250 | ||
Water System | Water Tank | l | 2800 | |
Max. Water Flow | l/min | 300 | ||
Aggregate Stone System | Aggregate Bin | M³ | 10 | |
Width of Conveyer Belt | mm | 650 | ||
Aggregate Delivery Capacity | kg/min | 1700 | ||
Cement System | Cement Bin | M³ | 0.5 | |
Cement Delivery Capacity | kg/min | 60 | ||
Model | / | HFC1251K2R1LZT | ||
Top Speed | km/h | 98 | ||
Rated Power | KW /(r/min) | 162/2500 | ||
Others | Outline Dimension of the Whole vehicle (L×W×H) | mm | 9735×2495×3410 | |
Full Load Weight | kg | 25000 | ||
Curb Weight | kg | 15200 |
